SEIKO specializes in the design, production, and sales of a wide range of maize flour milling machines, including large, medium, small, and mini models. Our small maize milling machines have a production capacity of approximately 20TPD, while our large-scale machines can reach a capacity of up to 300TPD.
Whether you need a maize milling machine, a full-scale maize grinding line, or a complete maize flour milling plant, we offer tailored systems backed by real-world performance data and global installation experience.
Inconsistent flour quality
Low maize extraction rates
High energy consumption
Difficulty in cleaning local maize varieties
Manual operation & labor dependency
SEIKO’s maize milling plants are engineered to address these pain points with automated, energy-efficient, and high-yield systems.
| Parameter | SEIKO 60TPD Plant | SEIKO 150TPD Plant | SEIKO 300TPD Plant |
|---|---|---|---|
| Extraction Rate | ≥ 78% | ≥ 80% | ≥ 82% |
| Power Consumption (kWh/t) | 50–55 | 45–50 | 40–45 |
| Automation Level | Semi-Auto | Full Auto | Full Auto |
| Occupancy (m²) | 300–450 | 600–800 | 1000–1500 |
| Operator Required | 3–5 people | 5–7 people | 8–10 people |
Start Your Maize Milling Project
Our maize milling machines and maize grinding machines are built with precision-engineered components that ensure high throughput, consistent flour quality, and long-term durability, even under 24/7 continuous operation.
| Component | Function | Performance Data / Specs |
|---|---|---|
| Vibratory Cleaning Screens | Removes large impurities like straw | ≥ 99% impurity removal efficiency, 3-layer screen deck |
| Destoners & Magnetic Separators | Removes stones & metals | Removes >98% of heavy impurities, magnetic strength ≥ 8000 Gauss |
| Roller Mills (6–10 sets) | Maize grinding with fineness control | Output: 1.2–1.5 tons/hour per set; Adjustable: 60–200 mesh |
| Hammer Mills (optional) | Used for coarse grinding or bran | Energy-saving design, ≤ 12 kWh/t for maize grits |
| Plansifters & Purifiers | Accurate flour grading & separation | 4–6 sections; Flour classification accuracy ≥ 96% |
| PLC-Control System | Digital monitoring of all operations | Siemens/Delta brand; ≤±0.5% control precision |
Materials: All contact parts are made of food-grade 304 stainless steel, corrosion-resistant and easy to clean.
Start Your Maize Milling Project
Whether you're launching a local facility or expanding into mass production, SEIKO’s maize milling plant is modular and configurable to your needs.
| Plant Capacity | Recommended Roller Mills | Floor Space Needed | Avg. Power Consumption | Daily Output (Flour) |
|---|---|---|---|---|
| 30TPD | 4–6 sets | 250–350 m² | 55–60 kWh/ton | ~24 tons |
| 100TPD | 8–10 sets | 500–800 m² | 45–50 kWh/ton | ~80 tons |
| 300TPD | 12–16 sets | 1000–1500 m² | 40–45 kWh/ton | ~250 tons |
Supports multiple end-product lines:
Maize flour (60–200 mesh)
Maize grits (0.6–1.2 mm)
By-products recovery (bran, germ)
Compatible with maize from different regions:
Africa: High-oil yellow maize
Southeast Asia: Soft white maize
Latin America: Mixed kernel types
Efficient Design: Our maize mill machines feature a flat-line design with a straight-line layout for all main components. This design simplifies installation and maintenance, ensuring smoother operations and easy accessibility for service.
Automated Operation: The entire milling process is fully automated and continuous, minimizing the need for manual intervention. The system requires no special workshop setup, making it ideal for various production environments.
Flexible and Scalable: Our maize milling systems are designed to be flexible, with extra space for future expansion. This ensures that as your production needs grow, the mill can easily scale up to meet demand. You can use it to produce high-quality cornmeal for various applications.
Independent and Combined Functionality: The peeler and corn mill can function independently or in tandem with other machines, offering greater flexibility in operations and production control.
Energy Efficient: SEIKO’s maize milling machines feature low power consumption while maintaining high efficiency. The use of imported grinding heads, grinding rollers, and chain drives ensures durability and low noise. With these features, maintenance costs are reduced by up to 70%.
Cost-Effective Investment: Compared to other manufacturers, SEIKO's maize mills offer over 50% savings in investment, making it a highly cost-effective solution for your milling business.
Labor Efficiency: SEIKO maize mills are designed to operate with fewer workers, significantly reducing labor intensity.
This fully engineered flour milling equipment is suitable for producing high-yield, high-quality, low-fat flour using state-of-the-art cleaning, grinding and packaging process technology. For example, a corn flour processing line includes the following parts:
This part grades, cleans and destones all the grains to be processed into flour.
Upon arrival at the factory, fresh maize undergoes the cleaning stage. This process involves a combination of sieving, brushing, and destoning techniques. Two husking machines are utilized for husking and degermination. The maize in the silo is lifted to the cleaning screen and destoner by a bucket elevator. The objective of cleaning is to eliminate large and small impurities from the maize. After the initial screening, the raw materials are directed to the destoner to remove stones. Additionally, the cleaning screen is equipped with a vacuum blower to suspend and separate small stones that cannot be removed by crushing. It can also eliminate the smallest impurities. Subsequently, the raw materials enter the maize brusher to eliminate dust, dirt, and other impurities from the maize's surface, which are screened out through the sieve plate . This step enhances the quality of the final product. It is essential to utilize slotted screens or suction devices to eliminate foreign matter such as husks, straw, and dust. As an additional precaution, a magnet is used to remove metal that may harm milling equipment. This process prolongs the life of the mill and milling equipment.
This section peels, degerminates, crushes and grades the grains.
This process removes the germ from the endosperm to acquire a more refined maize flour and extend the shelf life of the final product. The by-product can be utilized as a component of animal feed, further enhancing profitability.
This section grinds and screens the peeled, degerminated, crushed and classified granules. It also has a dust collector that helps reduce environmental pollution.
This step necessitates a combination of drum and sieve to disintegrate the product into maize flour and eliminate the remaining bran before packaging. If dehulling is necessary, two maize dehullers eliminate the outer husks and germs. After dehulling, they enter the crusher for primary crushing. The crushed material passes through two flour mills for grinding and is then sieved through a double sifter to achieve the fineness of maize flour. Maize flour that meets the standard is directly packaged, while maize flour that does not meet the standard continues to be ground, sieved, and then packaged to achieve the desired fineness. Final powders that do not meet the standard will be packaged as animal feed components.
This equipment packs the processed flour into 10kg, 25kg
Our main sales of maize milling equipment are exported to Africa, Nigeria, etc. - South Africa maize milling plant, maize milling plant, maize flour processing plant, maize flour processing plant; Common questions about maize processing equipment may be helpful to you.
What is the backbone of a country's economy? Agriculture! What is a food ingredient? Maize flour! I think these two can convince us to invest in changing this industry. Maize is not only a source of food but also a raw material for animal feed. The maize/maize processing business is profitable, and with the right location, purchasing the right equipment, and proper operation, you can get substantial returns.
Choosing a good, reliable maize flour machine supplier means you're halfway there. Our specially designed maize flour mill is compact and easy to install. With limited floor space and high efficiency, we will recommend the best maize milling machines for your market. Get professional advice now.
With rich experience in the maize milling industry, we can manufacture and supply various types of milling machinery, including 10 tons per day maize flour machine, 20 tons/day maize milling machine, 30 tons maize processing equipment, large milling machines of 50-500 tons per day. We customize flour machines of any capacity at 100% factory prices. Get a free quote.
As a leading manufacturer of maize milling machines, we adhere to high quality and affordable prices. All products are offered at 100% factory prices. However, specific prices vary because some processes and equipment are optional. So if you want to get a preliminary price, please submit your requirements, and we will provide you with a free quote. After that, we can adjust the equipment to meet your budget and market requirements during our cooperation!
