At SEIKO Grain Milling, we provide more than machines — we deliver integrated maize flour milling solutions designed for high-efficiency production, market adaptability, and long-term operational reliability.
Whether you need a maize milling machine, a full-scale maize grinding line, or a complete maize flour milling plant, we offer tailored systems backed by real-world performance data and global installation experience.
Inconsistent flour quality
Low maize extraction rates
High energy consumption
Difficulty in cleaning local maize varieties
Manual operation & labor dependency
SEIKO’s maize milling plants are engineered to address these pain points with automated, energy-efficient, and high-yield systems.
| Parameter | SEIKO 60TPD Plant | SEIKO 150TPD Plant | SEIKO 300TPD Plant |
|---|---|---|---|
| Extraction Rate | ≥ 78% | ≥ 80% | ≥ 82% |
| Power Consumption (kWh/t) | 50–55 | 45–50 | 40–45 |
| Automation Level | Semi-Auto | Full Auto | Full Auto |
| Occupancy (m²) | 300–450 | 600–800 | 1000–1500 |
| Operator Required | 3–5 people | 5–7 people | 8–10 people |
Start Your Maize Milling Project
Our maize milling machines and maize grinding machines are built with precision-engineered components that ensure high throughput, consistent flour quality, and long-term durability, even under 24/7 continuous operation.
| Component | Function | Performance Data / Specs |
|---|---|---|
| Vibratory Cleaning Screens | Removes large impurities like straw | ≥ 99% impurity removal efficiency, 3-layer screen deck |
| Destoners & Magnetic Separators | Removes stones & metals | Removes >98% of heavy impurities, magnetic strength ≥ 8000 Gauss |
| Roller Mills (6–10 sets) | Maize grinding with fineness control | Output: 1.2–1.5 tons/hour per set; Adjustable: 60–200 mesh |
| Hammer Mills (optional) | Used for coarse grinding or bran | Energy-saving design, ≤ 12 kWh/t for maize grits |
| Plansifters & Purifiers | Accurate flour grading & separation | 4–6 sections; Flour classification accuracy ≥ 96% |
| PLC-Control System | Digital monitoring of all operations | Siemens/Delta brand; ≤±0.5% control precision |
Materials: All contact parts are made of food-grade 304 stainless steel, corrosion-resistant and easy to clean.
Start Your Maize Milling Project
Whether you're launching a local facility or expanding into mass production, SEIKO’s maize milling plant is modular and configurable to your needs.
| Plant Capacity | Recommended Roller Mills | Floor Space Needed | Avg. Power Consumption | Daily Output (Flour) |
|---|---|---|---|---|
| 30TPD | 4–6 sets | 250–350 m² | 55–60 kWh/ton | ~24 tons |
| 100TPD | 8–10 sets | 500–800 m² | 45–50 kWh/ton | ~80 tons |
| 300TPD | 12–16 sets | 1000–1500 m² | 40–45 kWh/ton | ~250 tons |
Supports multiple end-product lines:
Maize flour (60–200 mesh)
Maize grits (0.6–1.2 mm)
By-products recovery (bran, germ)
Compatible with maize from different regions:
Africa: High-oil yellow maize
Southeast Asia: Soft white maize
Latin America: Mixed kernel types
If you are looking to buy maize milling machines, we are your best choice. We have various types and models to meet specific requirements. Additionally, we can offer the most competitive prices in the international market and ensure machine quality and production efficiency. In our maize processing machinery catalog, small-scale maize milling machines are the most popular as they can easily help customers start small maize milling businesses.
For entrepreneurs and investors looking to establish a maize processing business, understanding the equipment and costs involved is critical. The first step is sourcing high-quality maize milling machines for sale, which form the backbone of the operation. These machines are used to grind raw maize into fine flour, a staple ingredient in many regions. As part of your planning, a detailed maize milling business plan is essential. This plan should cover various aspects, such as production capacity, market demand, operational costs, and most importantly, the cost of machinery. The maize milling machine price can vary significantly based on the brand, size, automation level, and production capacity. Similarly, the maize grinding machine price may fluctuate depending on the technology used and the efficiency of the machine.
Investing in the right equipment, such as efficient maize grinding mills, is a major factor in determining the quality of your final product. These mills come in different types and sizes, and choosing the right one can enhance productivity while keeping energy consumption low. Whether you're setting up a small, medium, or large-scale operation, balancing the initial investment with long-term profitability is key. Careful research into equipment options and their pricing will ensure that your maize milling business is both competitive and sustainable in the long run.
Achieving systematic production with short time and high efficiency.
Advanced technology and reasonable structural design ensure efficient and durable performance.
Grain production process can be automated.
Small investment, energy-saving.
This fully engineered flour milling equipment is suitable for producing high-yield, high-quality, low-fat flour using state-of-the-art cleaning, grinding and packaging process technology. For example, a corn flour processing line includes the following parts:
This part grades, cleans and destones all the grains to be processed into flour.
Upon arrival at the factory, fresh maize undergoes the cleaning stage. This process involves a combination of sieving, brushing, and destoning techniques. Two husking machines are utilized for husking and degermination. The maize in the silo is lifted to the cleaning screen and destoner by a bucket elevator. The objective of cleaning is to eliminate large and small impurities from the maize. After the initial screening, the raw materials are directed to the destoner to remove stones. Additionally, the cleaning screen is equipped with a vacuum blower to suspend and separate small stones that cannot be removed by crushing. It can also eliminate the smallest impurities. Subsequently, the raw materials enter the maize brusher to eliminate dust, dirt, and other impurities from the maize's surface, which are screened out through the sieve plate . This step enhances the quality of the final product. It is essential to utilize slotted screens or suction devices to eliminate foreign matter such as husks, straw, and dust. As an additional precaution, a magnet is used to remove metal that may harm milling equipment. This process prolongs the life of the mill and milling equipment.
This section peels, degerminates, crushes and grades the grains.
This process removes the germ from the endosperm to acquire a more refined maize flour and extend the shelf life of the final product. The by-product can be utilized as a component of animal feed, further enhancing profitability.
This section grinds and screens the peeled, degerminated, crushed and classified granules. It also has a dust collector that helps reduce environmental pollution.
This step necessitates a combination of drum and sieve to disintegrate the product into maize flour and eliminate the remaining bran before packaging. If dehulling is necessary, two maize dehullers eliminate the outer husks and germs. After dehulling, they enter the crusher for primary crushing. The crushed material passes through two flour mills for grinding and is then sieved through a double sifter to achieve the fineness of maize flour. Maize flour that meets the standard is directly packaged, while maize flour that does not meet the standard continues to be ground, sieved, and then packaged to achieve the desired fineness. Final powders that do not meet the standard will be packaged as animal feed components.
This equipment packs the processed flour into 10kg, 25kg
Our main sales of maize milling equipment are exported to Africa, Nigeria, etc. - South Africa maize milling plant, maize milling plant, maize flour processing plant, maize flour processing plant; Common questions about maize processing equipment may be helpful to you.
What is the backbone of a country's economy? Agriculture! What is a food ingredient? Maize flour! I think these two can convince us to invest in changing this industry. Maize is not only a source of food but also a raw material for animal feed. The maize/maize processing business is profitable, and with the right location, purchasing the right equipment, and proper operation, you can get substantial returns.
Choosing a good, reliable maize flour machine supplier means you're halfway there. Our specially designed maize flour mill is compact and easy to install. With limited floor space and high efficiency, we will recommend the best maize milling machines for your market. Get professional advice now.
With rich experience in the maize milling industry, we can manufacture and supply various types of milling machinery, including 10 tons per day maize flour machine, 20 tons/day maize milling machine, 30 tons maize processing equipment, large milling machines of 50-500 tons per day. We customize flour machines of any capacity at 100% factory prices. Get a free quote.
As a leading manufacturer of maize milling machines, we adhere to high quality and affordable prices. All products are offered at 100% factory prices. However, specific prices vary because some processes and equipment are optional. So if you want to get a preliminary price, please submit your requirements, and we will provide you with a free quote. After that, we can adjust the equipment to meet your budget and market requirements during our cooperation!
